Peel rivet with four flower-shaped leaves provides a wider grip area. Ideal for applications in materials or plastics with low resistance to pressure. It is used for joining plastic – plastic / metal – plastic / metal – wood materials in applications with one side access. Peel Rivet is designed for easy and quick joining of hard materials to soft materials or low-resistance materials. The top of the rivet is made of four corners to separate the rivet from side to side. Thus, when the spider rivet is applied, it forms a large-age circle on top of the material and provides locking. The wide opening of the rivet reduces the load and clamping force, reducing the risk of material cracking or breakage. Peel When rivet is applied, a gap is formed in the center of the rivet’s head.
FEATURES AND BENEFITS
It is applied from one side.
Ideal for use in soft or low-resistance materials such as plastic, fiber, wood.
Suitable for use in large holes
Fast, simple and high quality application
When the rivet is applied, it does not damage the paint or coating on the material surface.
Resistant to temperature changes.
SCOPE OF APPLICATION
- Automotive industry
- Manufacture of trailers and caravans.
- Construction works (drywall partition wall, cladding, insulation, etc.)
- Floor
- Plastic parts
- Wood Industry
- Household Appliances
 Diameter |
|
|
|
|
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|
| 4.0 | 01.041211.40100 | 2 – 6.5 | 10.0 | 1.000 | 850 | |||||
| 01.041211.40120 | 12.0 | |||||||||
| 4.8 | 01.041211.48120 | 2 – 6 | 1.700 | 1.700 | ||||||
| 01.041211.48160 | 3 – 9 | 16.0 | ||||||||
| 01.041211.48200 | 8 – 14 | 20.0 | ||||||||
| 01.041211.48250 | 12 – 19 | 25.0 | ||||||||
| 01.041211.48300 | 16 – 24 | 30.0 | ||||||||
| 01.041211.48350 | 20 – 28 | 35.0 |
